TNMG160404/08/12
Coating color: Yellow, Blackish.
Standard size specification
CVD Coating
Hardness HRC30-45,
Application Scope- Steel, Stainless steel
Steel P20-40,
Stainless steel M20-M40,
Cast Iron: K10-25
Cnc lathe insert TNMG160404/08/12 machining steel, stainless steel, cast iron
TNMG160404/08/12-GF turning insert is well applied to workpiece steel, stainless steel, cast iron and it can work mild or high hardness workpiece HRC30-45, beside, it be alternative of finishing, semi-finishing, rough machining.
Coating color: Yellow, Blackish.
Standard size specification
CVD Coating
Hardness HRC30-45,
Application Scope- Steel, Stainless steel
Steel P20-40,
Stainless steel M20-M40,
Cast Iron: K10-25
| ISO Items | Dimensions(mm) | Grade | Cutting parameters | |||||
| l | ic | s | Φd | re | CVD | PVD | ||
| TNMG160404-GF | 16.5 | 9.525 | 4.76 | 3.81 | 0.4 | √ | ap:0.15-2.00mm fn:0.08-0.18mm/rev |
|
| TNMG160408-GF | 16.5 | 9.525 | 4.76 | 3.81 | 0.4 | √ | ap:0.25-2.00mm fn:0.08-0.25mm/rev |
|
| TNMG160412-GR | 16.5 | 9.525 | 4.76 | 3.81 | 0.4 | √ | ap:0.25-2.00mm fn:0.08-0.25mm/rev |
|
